Lider (Export Afrique) Porte-Char lames 4 essi

Syltrailer offers you 4-axle semi-trailers for transporting machinery from the Lider Trailer brand: Price on request.

Additional information:
VEHICLE ONLY AVAILABLE FOR EXPORT (AFRICA)

Characteristics of the general structure:
Number of axles: "4" and wheels: "16"
Number and position of axles with twin wheels: "All axles equipped with twin wheels"

Dimensions:
- Wheelbase (e): 8830 mm
- Axle spacing: 0-1: 6810 mm 1-2: 1350 mm 2-3: 1350 mm 3-4: 1350 mm
- Length: 13600 mm
- Width: 3000 mm
- Height: 3700 mm.
- Distance between the centre of the towing device and the rear of the vehicle: 12800 mm
- Length of the loading area: 11530 mm

Masses
- Mass of the vehicle in running order: 13000 kg,
- Distribution of this mass between the axles: 1. 2750 kg 2. 2750 kg 3. 2750 kg 4. 2750 kg
kg
- Technically permissible maximum masses
- Technically achievable maximum mass: 86000 kg
- Technically permissible mass on each axle: 1. 16000 kg 2. 16000 kg 3. 16000 kg 4. 1600 kg
- Technically permissible mass on each axle group: 64000 kg
- Maximum number of persons that may be registered/in service in a country
traffic
- Maximum permissible laden mass intended for registration/in service: 86000 kg
- Maximum permissible laden mass intended for each axle, registered/in service:
1. 16000 kg 2. 16000 kg 3. 16000 kg 4. 16000 kg
- Maximum permissible laden mass for each axle group, intended for registration/in service: 64000 kg
- Maximum technically permissible static mass at the coupling point of a semi-trailer or a central axle trailer: 22000 kg

Brakes:
- Mechanical/pneumatic trailer brake connections

Bodywork:
- Bodywork code: DA-Semi-Trailer

Coupling device:
Pgedsvl E Ifspfx Affow
- Approval number or approval mark of the coupling device (if equipped): E37*94/20*0195*00
- Characteristic values (1): D: .../ V: .../ S: ...lU:.... D:152 KN

Miscellaneous:
- Approved according to the design requirements for the transport of dangerous goods: yes/class(es): Yes
- For special purpose vehicles: designation in accordance with Annex II, section 5:

Option:
ABS
EBS

Do not hesitate to contact us.
